DC converter 4.75-23V to 1-17V Adjustable - 1.8A
WB462
Converter DC 4.75-23V to 1-17V Adjustable - 1.8A
Adjustable DC4.75-23V to 1-17V converter - 1.8A, non-isolated step-down module (BUCK).
Features
- Rectification: synchronous rectification
- Input voltage: DC 4.75V-23 V
- Output voltage: DC 1.0V-17V (adjustable, output & lt; Input)
- Output current: Rated current 1.8 A (3 A MAX, cannot be extended)
- Output ripple: 30 mV (no load)
- Dimensions: 17 x 11 x 4 mm (L x W x H) / 0.67 x 0.43 x 0.16 inches approx.
